3. If oil is not owing, ensure that there is oil in the
tank and that the area under the side cover is
clean; refer to Checking the Oil Level and Adding
Bar and Chain Oil ( page 18 ) and Servicing the
Guide Bar , Chain, and Drive Sprocket ( page 20 ) .
Adjusting the Chain
T ension
Service Interval : Before each use or daily
After each battery drain cycle
Ensure that the chain is properly tensioned.
A loose chain shortens the life of the drive sprocket
and the guide bar and may cause the chain to fall of f.
An overtightened chain overheats the guide bar and
chain, causing rapid wear , and may burn out the motor
or break the chain.
The chain tension is correct when you are able to use
a gloved hand to pull the chain smoothly around the
guide bar . The chain should remain in contact with
the bottom edge of the guide bar .
Also, check the chain tension of a new chain after a
few cuts; a new chain usually stretches and requires
adjustment after a few cuts.
DANGER
Contact with the pole saw teeth can cause
serious personal injury .
• Remove the battery pack before adjusting
or maintaining the pole saw .
• Always wear gloves when adjusting or
maintaining the pole saw .
1. Place the pole saw on a level surface and
remove the battery pack; refer to Removing the
Battery Pack ( page 17 ) .
2. Allow the saw chain to cool.
Important: Do not tension a hot chain; it
may contract as it cools, resulting in an
overtightened chain.
3. Inspect the guide bar for bends or damage,
replace if necessary .
4. T urn the bar cover knob counterclockwise to
loosen the bar cover , but do not remove it
( Figure 18 ).
g374237
Figure 18
1. Bar cover knob
5. Adjust the chain tension using the chain
tensioning screw ( Figure 19 ), and then secure
the side cover to the pole saw by turning the
bar cover knob clockwise before checking the
tension ( Figure 18 ).
• T o tighten the chain, turn the chain
tensioning screw clockwise.
• T o loosen the chain, turn the chain
tensioning screw counterclockwise.
19
