Toro Groundsmaster 1200 - Rear Cutting Unit Lift Arm Assembly

RearCuttingUnitLiftArmAssembly
g241358
Figure15
1.Locknut
8.Retainingring(2each)
15.Washerheadbolt
2.Hubsupportassembly
9.Thrustwasher(2each)16.Liftarmpinassembly
3.T aperedstud
10.LiftarmLHassembly
17.Hexnut
4.Greasetting11.Cylinderpin
18.Bolt
5.Sphericalbearing12.Greasetting19.LiftarmRHassembly
6.Retainingring
13.Roller20.Flatwasher
7.Flangenut
14.Spacertube
RemovingtheRearCuttingUnitLiftArmAssembly
Note:RefertoFigure15duringthisprocedure.
1.Parkthemachineonalevelsurface,lowerthecuttingunitsanddisengage
thePTO.Removethemaindriveshaftanddisconnectthemachine
fromthetowvehicle.Securethemachinewithtowbarjack;refertothe
Groundsmaster1200Operator’sManual.
2.Removethecuttingunitcovers.
3.Removetheliftcylindersfromthecuttingunitliftarms;refertoRemovingthe
CuttingUnitLiftCylinder(page4–9).
4.Removethewasherheadbolt(15)thatsecuretheliftarmpinassembly(16).
5.Supporttheliftarm(10)andslidetheliftarmpinassembly(16).
Chassis:ServiceandRepairs
Page3–18
Groundsmaster®1200Pull-BehindRotaryMower
18235SLRevA
