AssemblyoftheCuttingUnitLiftCylinder(continued)
C.Securethepiston(2)totheshaftwiththelocknut(1).Tightenlocknut:
•Sidecuttingunitcylinder5/8in.locknutto102Nm(75ft-lb).
•Rearcuttingunitcylinder1/2in.locknutto54Nm(40ft-lb).
4.Lubricateheadandpistonwithcleanhydraulicoil.Slidetheshaftassembly
carefullyintothecylinderbarrel.
IMPORTANT
Preventdamagewhenclampingthecylinder’sbarrelintoavise;
clamponthebarrelclevisonly.Donotcloseviseonbarrel.
5.Mountliftcylinderinaviseequippedwithsoftjawsbyclampingonthe
barrelclevis.
6.Tightentheexternalcollar(11)ontothecylinderbarrelandsecurewiththe2
setscrews.
Groundsmaster®1200Pull-BehindRotaryMower
Page4–13
HydraulicSystem:ServiceandRepairs
18235SLRevA
