Toro Groundsmaster 4010-D Service Manual

Groundsmaster 4000--D/4010--D Page 5 -- 15 Electrical System
Troubleshooting
CAUTION
Remove all jewelry, especially rings and
watches, before doing any electrical trouble -
shooting or testing. Also, disconnect the battery
cables unless the test requires battery voltage.
For effective troubleshooting and repairs, you must
have a good understanding of the electrical circuits and
components used on this machine ( see electrical
schematics and wire harness drawings in Chapter 10 --
Foldout Drawings).
If the machine has any interlock switches by--passed,
reconnect the switches for safety and efficient trouble-
shooting.
NOTE: Check the InfoCenter Display for possible oper -
ator advisories or faults whenever diagnosing machine
electrical problems.
Operator Advisories
The list below identifies the operator advisories t hat are
generated by the TEC controller. An advisory will be dis-
played on the InfoCenter Display. Typically, an advisory
can be eliminated with a change in machine controls by
the operator.
Advisory
Advisory Description
160 Inhibit start
161 Inhibit PTO
162 Inhibit cutting unit lower
163 Inhibit traction HIGH speed range
164 Inhibit traction LOW speed range
165 Inhibit traction
166 Inhibit cruise control
167 Derate traction setting
168 Inhibit traction teach (traction pedal calibration)
169 Engine shutdown
170 Recycle keyswitch (ignition switch)
171 Auto idle engaged
172 Calibrate (traction pedal)
173 Master address claim (front TEC controller)
174 Slave address claim (rear TEC controller)
175 Derate engine
Electrical
System

Toro Groundsmaster 4010-D Specifications

General

Transmission	Hydrostatic
Number of Blades	3
Deck Type	Rear Discharge
Turning Radius	18 inches
Tire Size Front	26 x 12-12
Tire Size Rear	20 x 10-10
Cutting Width	126" (3.2 m)
Cutting Height	1 to 6 inches
