4
InstallingtheHeadlights
(forMachineswithROPS
only)
Partsneededforthisprocedure:
1Rightheadlightmount
1
Leftheadlightmount
2
Coverpanel
8Plug
1Rightheadlightassembly
1
Leftheadlightassembly
Procedure
1.Unplugthewireharnessfromeachexistingheadlight.
2.Removetheheadlights(Figure6).
g188849
Figure6
1.Headlight2.Removethehardware
here.
3.Removeandretainthehardwarefromtheoperator’s
platform(Figure6).
4.Usingthefastenersthatyouremoved,installtheleft
andrightheadlightmountstotheexistingholesinthe
frontoftheoperator’splatform(Figure7).
g035974
Figure7
1.Headlightassembly3.Previouslyremoved
fasteners
2.Headlightmount
5.Removethefastenersfromtheheadlightassemblyand
usethemtomounttheheadlightstotheheadlight
brackets(Figure7).
6.Connectthewireharnesstotherightheadlight(Figure
8).
g036569
Figure8
1.Rightheadlightconnector
4.Connecttoexistingleft
headlightwireharness.
2.Connecttoexistingright
headlightwireharness.
5.Leftheadlightconnector
3.Frontturnsignalconnector
5
