G430557
2. Plug the male connector on the power
supply into the female connector
on the
low-voltage cable.
G430077
3. Use the 4 Allen-head screws to secure the
charging station.
G430076
4. Plug the power supply into an electrical outlet.
The indicator light on the charging station
should turn green.
Setup: Installing the Charging Station Page 4–13 3448-238 B
