Toro Haven 20459 - Replacing the Wheels; Removing the Wheels

Replacing the Wheels
Removing the Wheels
1. Press the stop button and wait for all moving parts to stop.
G430568.svg
2. Using a flat-head screwdriver , remove the
cap
from the wheel .
3. Remove the 3 bolts
.
4. Remove the wheel
.
Maintenance: Replacing the Wheels Page 6–5 3448-238 B
