RemovingtheExistingSeat
Model31654
NoPartsRequired
Procedure
Seatweight:38kg(84lb)
Note:Haveanotherpersonhelpyouremovetheseat
oruseasuitablecrane.
1.Disconnecttheconnectorfortheseat-switch
wireharnessfromtheconnectorofthemachine
wireharness(Figure5).
g036778
Figure5
2.Routetheconnectorfortheseat-switchwire
harnessthroughtheseatplatformandsecure
theconnectortotheseat.
3.Removethebootfromtheseatbaseasfollows
(Figure6).
A.Atthesidesoftheseat-baseboot,locateits
mountingtabsthatprotrudethroughtheslot
inthechanneloftheseatbase.
g037076
g037047
Figure6
1.Tabs(seat-baseboot)2.Slots(seat-basechannel)
B.Pulleachtabalongtheslotuntilthetabis
overtheholeandthenpullthetaboutand
awayfromtheseat-basechannel.
Note:Pullthebootforwardorrearward
dependingonwhichtabyouarethe
removing.
C.Whenallofthetabsareremovedfromtheir
slots,pulltherubberbootdown(Figure7).
