SECTION 5: KNOW YOUR LAWN TRACTOR
Figure 8
NOTE: Any reference in this manual to the RIGHT or LEFT side of the tractor is observed from operator’s position.
A Systems Indicator Monitor/Hour Meter G Throttle / Choke Control
B PTO (Blade Engage) Lever H Ignition Switch Module
C Parking Brake Lever I Brake Pedal
D Choke Control (if equipped) J Drive Pedal
E Cruise Control Lever K Deck Lift Lever
F Cup Holder
A
G
K
J
I
E
B
C
H
F
D
NOTE: Steering Wheel not shown for clarity.
