SPECIFICATIONS & MAINTENANCE
2-18
Toro Single Stage Snow Service Manual
7. Unscrew the oil ll cap and remove it (Fig. 014).
8. With the machine in the operating position, carefully
pour oil into the oil ll hole. Wait 3 minutes for the
oil to settle and add enough to bring it to the point of
overow (Fig. 016).
NOTE
You may tip the machine forward (handle up) to make
adding oil easier. Remember to return the machine to the
operating position before checking the oil level.
IMPORTANT
Do not tip the machine all the way forward onto its nose, or
fuel may leak out of the machine.
Max ll: 20 oz. (0.6 l), type: automotive detergent oil with
an API service classication of SJ, SL, or higher.
Use Fig. 015 to select the best oil viscosity for the outdoor
temperature range expected.
9. Screw the oil ll cap into the oil ll hole, and hand
tighten it securely.
10. Wipe up any spilled oil.
11. Dispose of the used oil properly at a local
recycling center.
A. Oil ll cap
Fig. 014
Fig. 015
Fig. 016
