ENGINE MOUNTING
5-4
5. Remove the four engine mounting bolts that connect
the engine to the side plate (A) (Fig. 005).
6. Remove the engine from the chassis (Fig. 006).
1. Remove the shroud as outlined in Chapter 3.
2. Remove the belt cover and remove belt as outlined
in chapter 2.
3. Remove the engine pulley bolt and remove pulley
(Fig. 003).
4. From the underside of the chassis, remove the two
engine mounting bolts (A) (Fig. 004).
For engine service information,
see Single Stage Snow Engine
Service Manual LC154FS/
LC154FDS (87cc), PN 492-9233
or LC168F/LC168FD (163 cc),
PN 492-9230
Fig. 005
A
A
A
A
Fig. 006
Toro Single Stage Snow Service Manual
Fig. 004
A
A
Engine Removal 18 Inch Models
Fig. 003

Toro Power Clear 621 Specifications

General

Engine Type	4-Cycle
Engine Displacement	212cc
Fuel Type	Gasoline
Clearing Width	21 inches
Throw Distance	35 feet
Starting System	Recoil
Chute Control	Manual
Drive System	Power Propel
Warranty	2-Year Full Coverage
