016
Figure 13
Self-propel drive bail
Adjusting the Cutting Height
Each wheel is adjusts individually with a wheel height
adjustment lever. Cutting heights are 1 inch (25 ram);
1-1/2 inches (38 nnn); 2 inches (51 nnn); 2-1/2 inches
(64 nnn); 3 inches (76 ram); and 3-1/2 inches (89 nnn).
POTENTIAL HAZARD
* Adjusting the height-of-cut levers could bring
your hands into contact with a moving blade.
WHAT CAN HAPPEN
* Contact with a rotating blade can cause serious
iNury.
HOW TO AVOID THE HAZARD
* Stop the engine and wait for all movement to
stop before adjusting the cutting height.
* Do not put fingers under the housing when
adjusting the cutting height.
1. Pull the wheel height adjusmlent lever toward the
wheel and move it to the desired position (Fig. 14).
/
Figure 14
Wheel height adjustment lever
1021
2. Release the wheel height adjustment lever and seat it
securely in the desired notch.
Note: Set all four wheels at the same height.
Operating Tips
General Tips
* Review the safety instructions and read this manual
carefully before operating the lawn mower.
Clear the area of sticks, stones, wire, branches, and
other debris which could be picked up or hit by the
blade and become thrown objects.
Keep everyone, especially children and pets, away
from the area of operation.
Avoid striking trees, walls, curbs, or other solid
objects. Never deliberately mow over any object.
If the lawn mower strikes an object or starts to vibrate,
innnediately stop the engine, disconnect the spark plug
wire, and examine the lawn mower for damage.
Maintain a sharp blade throughout the cutting season.
Periodically file down nicks on the blade.
Replace the blade when necessary with an original
Toro replacement blade.
Only mow dry grass or leaves. Wet grass and leaves
tend to clump on the yard and may cause the lawn
mower to plug or the engine to stall.
POTENTIAL HAZARD
* Wet grass or leaves can cause you to slip and
contact the blade.
WHAT CAN HAPPEN
* Blade contact can seriously injure you.
HOW TO AVOID THE HAZARD
* Mow only in dry conditions.
Clean clippings or leaves from the underside of the
lawn mower deck after each mowing. See (7eal_il_g
the Ul_derside of the Lawl_ Mower Housil_g on
page 14.
* Keep the engine in good running condition.
POTENTIAL HAZARD
* Operating a lawn mower with its engine
running at a speed greater than the factory
setting can cause an unsafe operating condition.
WHAT CAN HAPPEN
* The lawn mower could throw a part of the
blade or engine into the operator's or
bystander's area and cause serious personal
injury or death.
HOW TO AVOID THE HAZARD
* Do not change the engine speed setting.
* If you suspect the engine speed is faster than
normal, contact your Authorized Service
Dealer.
10
