Toro Snow Commander User Manual

Snow Commander Service Manual 7 - 11
MAINTENANCE
SPECIFICATIONS (General)
TORQUE SPECIFICATIONS
LUBRICATION
Item Description
Engine Mfg. The Toro Company 141cc E series (R tek)
Fuel Mix Ratio 50:1
Spark Plug NGK
BPMR4A or equivalent
Fuel Capacity 1.2 US quart (1.1 l)
Weight 113 lbs. (51.4 kg) (recoil start)
115 lbs. (52.3 kg) (electric start)
Width 24.3” (61.7 cm)
Height 40.4” (102.6 cm) (highest point)
Length 51.3” (130.3 cm)
Chute Rotation 210 degrees
Chute Throat Diameter 6.2” (15.7 cm)
Impeller Diameter 10” (25.4 cm)
Rotor Drive Reduction 3.95:1
Description / Where Used
Torque Value
In-Lbs N·cm
Engine Pulley
Square Head Set Screw
Allen Head Set Screw
120 - 150
60 - 80
1355 - 1694
678 - 904
Nut On Recoil Support 90 - 120 1016 - 1355
Engine Mounting Screws 170 - 220 1920 - 2483
Rotor Pulley Capscrew 100 1125
Brake Arm Shoulder Bolt 170 - 250 1920 - 2824
(Must pivot freely)
Plastite Screws Tighten securely, but do not deform the plastic
Belt Cover Top Screw (has an O-ring on it) Tighten to compress O-ring to .08” - .11” (2.03 - 2.79mm) thick.
Engine - “Fuel and Oil Requirements” on page 1 - 6.
Engine crankshaft pulley. Apply anti-seize compound to shaft before installation of pulley.
Apply a light coat of #2 general purpose grease to the brake arm, shoulder bolt, and washers.
