Toro® - SnowMaster® Service Manual
3-4 Table of Contents
CHASSIS
1. Lower Chute
2. Chute Guide
3. Chute Post
4. Chute Gear
5. Chute
6. Chute Ring
7. Gear Chute Mount
8. Face Gear
9. Gear Chute Cover
10. LH Upper Shroud
11. RH Lower Shroud
12. Housing Kicker
1
2
3
4
5
6
7
8
9
10
11
12
Figure 14
Chute Asm.
