Toro® - SnowMaster® Service Manual 3-3
Chassis
3
Table of Contents
CHASSIS
1. Lower Chute
2. Chute Guide
3. Chute Support Tube Bracket
4. Chute Post
5. Chute Gear
6. Chute
7. Chute Handle
8. Spring Cover
9. Extension Spring
10. LH Upper Shroud
11. RH Lower Shroud
12. Housing Kicker
13. Chute Ring
Figure 13
Chute Asm.
7
8
5
9
3
10
4
11
12
1
2
13
6
