Toro® - SnowMaster® Service Manual 3-23
Chassis
3
Table of Contents
CHASSIS
Transmission Replacement (Cont.)
Replacement (Cont.)
6. Install the tensioner spring. Check for proper belt
routing and tension (Figure 72).
7. Install the belt covers and install all mounting bolts.
8. Install the wheels. Add anti-seize to lock wheels.
9. Replace all shrouds, the drive belt and cover.
Figure 72
