7. Slide the rod through the second grass-deector
pivot ( Figure 68 ).
8. Insert the rod at the front of the grass deector
into the bracket on the deck.
9. Secure the rear end of the rod into the mower
with a nut (3/8 inch) as shown in Figure 68 .
Important: The grass deector must be
spring-loaded in the down position. Lift the
deector up to test that it snaps into the
full-down position.
Cleaning
W ashing the Underside of
the Mower Deck
Service Interval : After each use
Important: Y ou can wash the machine with a mild
detergent and water . Do not pressure wash the
machine. A void excessive use of water , especially
near the control panel, under the seat, around the
engine, hydraulic pumps, and motors.
W ash the underside of the mower deck after each use
to prevent grass buildup for improved mulch action
and clipping dispersal.
1. Park the machine on a level surface, disengage
the blade-control switch (PT O), and move the
motion-control levers outward to the P ARK
position.
2. Shut of f the engine, remove the key , and wait
for all moving parts to stop before leaving the
operating position.
3. Attach the hose coupling to the end of the
mower washout tting, and turn the water on
high ( Figure 69 ).
Note: Spread petroleum jelly on the washout
tting O-ring to make the coupling slide on
easier and protect the O-ring.
g020098
Figure 69
1. W ashout tting 3. O-ring
2. Hose
4. Coupling
4. Lower the mower to the lowest height-of-cut.
5. Sit on the seat and start the engine.
6. Engage the blade-control switch and let the
mower run for 1 to 3 minutes.
7. Disengage the blade-control switch, shut of f the
engine, remove the key , and wait for all moving
parts to stop.
47
