MOWER DECKS
TimeCutter™ Z Service Manual 7 - 11
7
Remove the nut and washer securing the spindle
pulley.
Slide the pulley off the shaft.
Remove the shaft, washer, and blade assembly
from the spindle housing.
0702-0714
0702-0726
0702-0715
Spindle Bearing Replacement
To Next Page
