14
3. Move the PTO (power take off) to Off (Fig. 5).
1
m–4201
2
Figure 5
1. PTO—On 2. PTO—Off
4. Move the throttle lever to Choke before starting a cold
engine.
Note: A warm or hot engine may require choking. After the
engine starts, move the throttle lever to Fast.
5. Turn the ignition key to Start to energize the starter.
When the engine starts, release the key.
Important Do not engage the starter for more than 10
seconds at a time. If the engine fails to start, allow a 60
second cool-down period between attempts. Failure to
follow these instructions can burn out the starter motor.
6. After the engine starts, move the throttle lever to Fast
(Fig. 6). If the engine stalls or hesitates, move the
throttle lever back to Choke for a few seconds. Then
move the throttle lever to the desired setting. Repeat
this as required.
m–5126
4
3
2
1
Figure 6
1. Engine
2. Choke
3. Fast
4. Slow
m–4268
1
2
3
4
Figure 7
1. Off
2. Run
3. Start
4. Ignition
Stopping
1. Move the throttle lever between Slow and Fast (Fig. 6).
2. Move the PTO to Off (Fig. 5).
3. Turn the ignition key to Off (Fig. 7).
4. Pull the wire off of the spark plug(s) to prevent the
possibility of someone accidentally starting the machine
before transporting or storing the machine.
5. Close the fuel shut-off valve under the front of the fuel
tank before transporting or storing the machine.
Important Make sure the fuel shut-off valve is closed
before transporting or storing machine, as fuel leakage may
occur.
Operating the Power Take Off
(PTO)
The power take off (PTO) switch engages and disengages
power to the electric clutch.
Engaging the PTO
1. Release pressure on the traction control levers and place
the machine in neutral.
2. Move the throttle to the Fast position.
3. Pull out on the PTO switch to engage it (Fig. 8).
1
m–4201
2
Figure 8
1. PTO—On 2. PTO—Off
Disengaging the PTO
Push the PTO switch to Off (Fig. 8).
