Toro TimeCutter Z420 User Manual

105-7015
108-2392
106-2224
1. Throttle 7. Headlights
2. Choke
8. Engine—stop
3. Fast
9. Engine—run
4. Continuous variable setting
10. Engine—start
5. Slow
11. Ignition
6. Power take-off (PTO), Blade
control switch on some
models
108-6109
1. To push the machine, move tow levers forward and then
out to lock them into position.
106-8717
1. Read the instructions before servicing or performing
maintenance.
2. Check tire pressure every 25 operating hours.
3. Grease every 25 operating hours.
4. Engine
106-8742
1. Parking brake
106-8743
1. Height of cut
9

Toro TimeCutter Z420 Specifications

General

Cutting Width	42 inches
Ground Speed Forward	7 mph
Ground Speed Reverse	3 mph
Deck Type	Fabricated
Fuel Capacity	3 gal
Transmission	Hydrostatic
Cutting Height	1.5 - 4.5 in
Transmission System	Hydrostatic
Warranty	3-year limited
