Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
1
Nopartsrequired
–
Connectthebattery.
2
Nopartsrequired
–
Checkthemoweradjustment.
IgnitionKey1
Hosecoupling1
Operator'sManual
1
EngineOperator'sManual
1
3
OperatorTrainingMaterial
1
CompletetheSetup.
1
ConnectingtheBattery
NoPartsRequired
Procedure
1.Locatethebatteryandnegativebatterycableinthe
centerofthemachine.
2.Removetheblackplasticcapfromthenegative
batterypost.Removethefastenersfromthenegative
batterycableandusethemtosecurethenegative
batterycabletothenegativebatterypost(
Figure4).
G010257
1
2
3
5
4
Figure4
1.Bolt4.Negativebatterypost
2.Washer5.Nut
3.Negativebatterycable
2
CheckingtheMower
Adjustment
NoPartsRequired
Procedure
Adjusttheside-to-sidelevelandthefront-to-rearblade
slope.UsetherelevantproceduresintheOperator's
Manualtoverifythedeckislevelandmakeany
adjustmentsasnecessary.RefertotheOperator'sManual
formoreinformation.
3
CompletingtheSetup
Partsneededforthisprocedure:
1IgnitionKey
1Hosecoupling
1
Operator'sManual
1
EngineOperator'sManual
1
OperatorTrainingMaterial
Procedure
CheckingtheTirePressure
