Toro TITAN MX4880 - Drive System Maintenance; Checking the Tire Pressure; Hydraulic System Maintenance; Checking the Hydraulic Oil Level

Figure47
1.PositiveBatteryPost
3.Red(+)ChargerLead
2.NegativeBatteryPost
4.Black(-)ChargerLead
ServicingtheFuses
Theelectricalsystemisprotectedbyfuses.Itrequires
nomaintenance,however,ifafuseblowscheckthe
component/circuitforamalfunctionorshort.
Fuses:
•Main,30amp,blade-type
•Engine,20amp,blade-type
1.Thefusesarelocatedonrighthandconsolenextto
theseat(
Figure48).
2.Toreplacethefuses,pulloutonthefusetoremove
it.
3.Installanewfuseofthesameamperageremoved
(
Figure48).
30
25
1 2
3
G015037
4
Figure48
1.30amp
3.Openaccessoryslot
2.25amp4.Fuseblock
41
