Figure10
•Tostop,releasethetractioncontrol(Figure6).
Note:Thefartheryoumovethetractioncontrolin
anydirection,thefasterthemachinewillmoveinthat
direction.
BoomElevationLever
Tolowertheboom,slowlymovetheleverforward
(Figure11).
Toraisetheboom,slowlymovetheleverrearward
(Figure11).
Figure11
1.Lowertheboom2.Raisetheboom
BoomElevationLock
Theboomelevationlocksecurestheboomelevation
leversothatyoucannotpushitforward.Thishelpsto
ensurethatnoonewillaccidentallylowertheboom
duringmaintenance.Securetheboomwiththelock
anytimeyouneedtostopthemachinewiththeboom
raised.
Tosetthelock,liftuponitsoitclearstheholeinthe
controlpanelandswingittotherightinfrontofthe
boomelevationlever,pushingitdownintothelocked
position(Figure12).
Figure12
1.Boomelevationlever2.Boomelevationlock
TrencherControlLever
Todigwiththetrencher,rotatetheleverrearwardand
pullitdowntothereferencebar(Figure13,number1).
Toreversethetrencherhead,rotatetheleverrearward,
thenmoveitleftintotheupperslot(Figure13,number
2).
Ifyoureleasethelever,itwillautomaticallyreturnto
theneutralposition(Figure13,number3),stoppingthe
chain.
Figure13
1.Forward3.Neutral
2.Reverse
15
