5.4 Transom mount
The tilt mechanism allows both tilting and trimming the motor.
You can tilt the motor to remove it from the water (e.g. when it is not in use or when you
land the boat in shallow water).
Trimming allows you to set the motor perfectly to the water surface. For this there are 4
possible trimming positions.
See chapter 4.1 (Fitting the drive onto the boat) to find out how to tilt and trim the motor.
Thekickleverinthe“Tilt/Autokick-up”positionenablesthemotortobekickedupifit
touches the bottom. In this position it is not possible to reverse at full speed.
Automatickick-upisswitchedoffinthe“Lock”position.Thisenablesreversingatfull
speed.
• Pleaseensurethatthekickleverfor
reversdriveisinthe“Lock”position.
