Printer Specification
3" portable printer ( Direct Thermal )
Plus model Standard model
GH30 (Bluetooth) GH40 (WLAN) GS30 (Bluetooth) GS40 (WLAN)
BASIC
SPECIFICATIONS
Media Types Receipt / Tag / Label Receipt
Resolution 203dpi ( 8dots/mm )
Max. Print speed Target : Max 6" (152mm) / sec
Max. Print Width 72mm (2.9")
Effective Print length 995mm
LCD TFT Color LCD, 128x128dots, 262K color with Backlight
Operating Switch Three operation keys: POWER, FEED, and PAUSE
Peel-off function Available Not Available
Barcode
UPC-A/E, EAN8/13,UPC-A add on 2&5,EAN-8/13 add on 2&5,Code39,
Code93,Code128, EAN128,NW7, MSI,Industrial 2 of 5,ITF, Postnet,RM4SCC,
KIX-code,Plessey, GS1 Databar
Two Dimensional
Code
Data Matrix, PDF417,Maxicode, QR code,Micro PDF417, Micro QR, GS1 Data
Matrix
Font
Bitmap: 21types, Outline: 4types, Chinese-simp 24x24(GB18030),
Optional: Hungle 24x24 or Japanese gothic 16x16, 24x24, mincho 32x32
alternate to chinese font(TTF)
Weight (with battery) 700g 700g
Physical dimension Width: 116mm
Depth: 150mm
Height: 80mm
Color
Mold Cover: Jet Black
Elastomer: Shadow grey
Battery 2.5 AH(18.5Wh) Li-Ion battery
Operating
temperature
-15 to 50 (5° to 122° F)
Operating humidity
(No condensation)
25~85% RH
Charging temperature
AC adaptor: 0° to 40° C(32° to 104° F)
Wireless charger: 0° to 35° C(32° to 99° F)
Drop strength 1.6m ( 5.3ft) 6way multiple drops/6way, with cover closed
Drip resistance IP54 excluding media path (with carry case)
ELECTRONICS
SPECIFICATIONS
Maximum Rating
8.4V/2.5A(TBD) : Battery drive
19.5V/2A(TBD) : Charging current
8.4V/2.5A(TBD) : Battery drive
19.5V/2A(TBD) : Charging current
Memory ROM: 64MB, RAM: 32MB ROM: 64MB, RAM: 16MB
Interface
Bluetooth
4.0(Bluetooth
Smart Ready:
BR/EDR, BLE
dual)
Wireless LAN
(802.11b/g/n)
Bluetooth
4.0(Bluetooth
Smart Ready:
BR/EDR, BLE
dual)
Wireless LAN
(802.11b/g/n)
USB 2.0(Full Speed)
NFC ISO/IEC14443 Type A, NFC Forum Type2, 888byte
SUPPLY
SPECIFICATIONS
Media Width Receipt / Label model: 24mm - 80mm (adjustable)
Media Length
Batch: 7.0mm - 997.0mm
Strip: 10.0mm - 60.0mm
Media Pitch
Batch: 10.0mm - 999.0mm
Strip: 13.0mm - 67.0mm
Media thickness 0.0508mm ~ 0.165mm
Max. Roll Size ø 66.8mm (2.6")
Roll Direction Outside
