6. PRINTER SPECIFICATIONS ENGLISH VERSION EO1-33059
6. PRINTER SPECIFICATIONS
E6- 1
6. PRINTER SPECIFICATIONS
This section describes the printer specifications.
Model
Item
B-SX5T-TS22-QM-R
Dimension (W × D × H) 291 mm × 460 mm × 308 mm (11.5” × 18.1” × 12.1”)
Weight 44.1 lb (20 kg) (Media and ribbon are not included.)
Operating temperature range 5°C to 40°C (40°F to 104°F)
Relative humidity 25% to 85% RH (no condensation)
Power supply Universal switching power source AC100V to 240V, 50/60Hz±10%
Input voltage AC100 – 240V, 50/60 Hz ±10%
During a print job 100V: 3.0 A, 144 W maximum 240V: 1.3 A, 142 W maximum Power
consumption
During standby 100V: 0.19 A, 13 W maximum 240V: 0.17 A, 21 W maximum
Resolution 12 dots/mm (306 dpi)
Printing method Thermal transfer or Thermal direct
Printing speed 76.2 mm/sec. (3 inches/sec.)
127.0 mm/sec (5 inches/sec.) For details, refer to Section 7.1.1.
203.2 mm/sec (8 inches/sec.)
Available media width (including
backing paper)
30.0 mm to 140.0 mm (1.2 inches to 5.5 inches)
Effective print width (max.) 128.0 mm (5 inches)
Issue mode Batch
Strip
Cut (Cut mode is enabled only when the optional Cutter Module is
installed.)
LCD Message display 16 characters × 2 lines
