NO Control Function
a
USB jack Connect a USB ash drive.
b
1
Turn the power on or restores the unit to the standby mode.
c
B/X
Playback/Pause.
d
x
Stop play.
e
Z
Open or close the disc compartment.
f
IR Sensor Point the remote control at the IR sensor.
g
Display panel Show information about the current status of this unit.
h
Disc compartment Load a disc into the disc drive.
Main Unit
NO Control Function
a
AC power cord Connect to a standard AC outlet.
b
COAXIAL jack Output digital audio signals when connecting the coaxial digital cable.
c
HDMI OUTPUT jack
Output video/audio signals to a connected TV, monitor or AV amplifier.
Connect to a TV, monitor or AV amplifier equipped with HDMI input.
d
LAN jack
When not using Wi, use this to connect to a network with an always-on broadband
connection. It is reserved for future usage of BD-Live™, bonus content and External
Control.
To Next Page
