1.TROUBLESHOOTING FOR THE HARDWARE
36 Clearing a Paper Misfeed
 Job Separator
The procedure below is for e-STUDIO2020AC/2520AC and e-STUDIO2528A/3028A with the Job Separator installed.
However, it does not apply to e-STUDIO2525AC/3025AC/3525AC/4525AC/5525AC/6525AC and e-STUDIO3528A/4528A/
5528A/6528A Series with the Job Separator installed.
 Be careful not to let your fingers be caught between the equipment and the automatic duplexing unit cover.
This could injure you.
 Do not touch the fuser unit or the metal portion around it.
Since they are very hot, you could be burned or the shock could cause you to get your hand injured in the machine.
1
Open the automatic duplexing unit cover on the right.
2
Open the cover inside of the equipment.
3
Remove the misfed paper.
4
Close the cover inside of the equipment.
5
Close the automatic duplexing unit cover.

Toshiba E-STUDIO 4525AC Specifications

General

Print Technology	Laser
Max Print Resolution	1200 x 1200 dpi
Max Paper Size	A3
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Warm-up Time	Approx. 20 seconds
Hard Disk Drive	320 GB
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Maximum Paper Size	A3
Connectivity	USB, Ethernet
Memory	4 GB
Fax Transmission Speed	33.6 kbps
Print Speed	45 ppm
