1 TROUBLESHOOTING FOR THE HARDWARE
22 Clearing a Paper Jam
4
Lower the transfer unit carefully and then close the automatic duplexing unit.
Paper jam on the paper transport path
Be careful not to let your fingers be caught between the equipment and the duplexing unit or automatic duplexing
unit.
This could injure you.
1
Open the automatic duplexing unit on the right.
2
Remove paper jammed on the paper transport path
above the fuser unit. (Only for e-STUDIO356/456)
3
While holding the green lever to lift up the transfer
unit, remove the jammed paper.
2
1
1
Open the automatic duplexing unit on the right.
To Next Page
