1.TROUBLESHOOTING FOR THE HARDWARE
Clearing a Paper Jam 35
1 TROUBLESHOOTING FOR THE HARDWARE
 Paper jam in the Saddle Stitch unit of the Saddle Stitch Finisher MJ-1106
(optional)
1
Remove the jammed paper from the exit side of the
Saddle Stitch unit.
2
Open the front cover of the finisher.
3
Holding the green knob, move the guide to the right.
4
Raise the lever and open the upper receiving tray of
the finisher.
5
Open the cover of the Hole Punch Unit when it is
installed.
2
1
