SETTING ITEMS (ADMIN)
- 280 -
Setting the TCP/IP protocol (IPv6)
You can set the TCP/IP v6 protocol.
In IPv6 setting operation, you can enable or disable the IPv6
protocol in this equipment, as well as set the IPv6 address, for
example, by selecting the addressing mode.
How the IPv6 address is acquired depends on the addressing
mode you select.
• When you select [MANUAL]:
You assign the IPv6 address, prefix and default gateway
manually. In this mode, it is possible to register one IPv6
address.
P.281 "Setting the IPv6 protocol manually"
• When you select [STATELESS]:
The IPv6 address is acquired automatically from the
DHCPv6 server and routers. In this mode, it is possible to
register up to nine IPv6 addresses.
P.282 "Setting the IPv6 protocol automatically (in a
stateless network environment)"
Memo
• Up to seven IPv6 addresses can be acquired from
routers. One IPv6 address can be obtained from the
DHCPv6 server. And, one link-local address is
generated automatically.
• When you select [STATEFUL]:
The IPv6 address is automatically acquired from the
DHCPv6 server. In this mode, it is possible to register one
IPv6 address.
P.283 "Setting the IPv6 protocol automatically (in a
stateful network environment)"
Memo
• If Duplicate Address Detection (DAD) detects duplicate
addresses, the message “IPv6 ADDRESS CONFLICT”
is displayed on the touch panel.
Item name Description
ADDRESS MODE • DYNAMIC (When TCP/IP is set by
Auto-IP addressing or DHCP
server)
Select [DYNAMIC] when you do not
know the TCP/IP settings that
should be assigned to the
equipment. If [DYNAMIC] is
selected when your network
supports the DHCP, the IP address,
subnet mask, default gateway,
primary WINS server address,
secondary WINS server address,
POP3 server address, and SMTP
server address are acquired from
the DHCP server. If the DHCP is
not supported, an appropriate IP
address is assigned to this
equipment by the auto-IP
addressing function. However, the
auto-IP addressing may not work
properly if a router is placed in the
network.
• NO AUTO IP (When TCP/IP is set
using only the DHCP server)
Select [NO AUTO IP] when the
equipment is connected to a local
area network with a DHCP server
and you want to set the TCP/IP not
using the auto-IP addressing
function, but only the DHCP. When
[NO AUTO IP] is selected, the IP
address, subnet mask, default
gateway, primary WINS server
address, secondary WINS server
address, POP3 server address,
and SMTP server address are
acquired from the DHCP server,
and the IP address assignment by
the auto-IP addressing function
disabled.
• STATIC (When connecting to a
local area network using static IP
addresses)
Select [STATIC] and specify an IP
address when connecting to a local
area network where static IP
addresses are used. Also set the
subnet mask and default gateway
as required.
IP ADDRESS
SUBNET MASK
GATEWAY
Press [IP ADDRESS] and enter the IP
address of this equipment using the
digital keys.
Enter the subnet mask and default
gateway as required.
Use the arrow buttons to switch the
active box.
• This item is enabled only when
[STATIC] is selected for [ADDRESS
MODE].
To Next Page
