Electrical supply / cable specifications
Wiring specifications (power line)
Description
Model Name
HWS
Power Supply
Current
(Max)
Install
Fuse
Rating
Power
Cable
Connection
Destination
Outdoor
Unit
Power
Power
Input
1404H-E
220V-230V ~
50Hz
22.8A
25A
≥2.5mm
2
L, N
-
1104H-E
220V-230V ~
50Hz
22.8A
25A
≥2.5mm
2
804H-E
220V-230V ~
50Hz
19.2A
20A
≥2.5mm
2
1604H8(R)-E
380-400V 3N~
50Hz
14.6A
16A
≥2.5mm
2
L1, L2, L3,
N
-
1404H8(R)-E
380-400V 3N~
50Hz
14.6A
16A
≥2.5mm
2
1104H8(R)-E
380-400V 3N~
50Hz
14.6A
16A
≥2.5mm
2
Hydro
unit
electric
heater
power
Power
input
for
back
up
heater
1404XWHM3-E
220V-230V ~
50Hz
13A
16A
≥1.5mm
2
L, N
TB02
1404XWHT6-E
380-400V 3N~
50Hz
13A (13Ax2P)
16A
≥1.5mm
2
L1, L2, L3,
N
1404XWHT9-E
380-400V 3N~
50Hz
13A (13Ax3P)
16A
≥1.5mm
2
804XWHM3-E
220V-230V ~
50Hz
13A
16A
≥1.5mm
2
L, N
804XWHT6-E
380-400V 3N~
50Hz
13A (13Ax2P)
16A
≥1.5mm
2
L1, L2, L3,
N
804XWHT9-E
380-400V 3N~
50Hz
13A (13Ax3P)
16A
≥1.5mm
2
Power input for DHW
cylinder heater
220V-230V ~
50Hz
12A
16A
≥1.5mm
2
L, N
TB03
Outdoor – hydro
unit connection
-
-
-
-
≥1.5mm
2
1, 2, 3
TB01
Hydro unit to DHW
cylinder
-
-
-
-
≥1.5mm
2
1, 2
TB03
Wiring specification (control line)
Description
Line Spec
Current (Max)
Length (Max)
Cable Diameter
Connection
Destination
3 way diverting
valve
2 or 3 wire
100mA
12m
1.0mm
2
7, 8, 9 (TB05)
2 way valve
(cooling)
2 wire
100mA
12m
1.0mm
2
3, 4 (TB05)
3 way mixing
valve (2 zone)
3 wire
100mA
12m
1.0mm
2
1, 2, 3
or
2, 3, 4
(TB04)
2 zone thermo
sensor (TFI)
2 wire
100mA
5m
1.0mm
2
C, D (TB06)
HW cylinder
thermo sensor
(TTW)
2 wire +GND
(screened cable)
100mA
5m
1.0mm
2
A, B (TB06)
2
nd
remote
controller
2 wire
50mA
50m
≥ 0.5mm
2
1, 2 (TB07)
