Sensor Temperature Monitoring Function
The sensor sensing temperature is displayed on the remote controller. This function allows you to make sure whether
the sensor is installed properly.
1) Press + buttons for four seconds or more.
2) Select the Code No. with the TEMP. buttons.
Control Temperature (Hot water cylinder)
Control Temperature (Zone1)
Control Temperature (Zone2)
Remote controller sensor temperature
Condensed temperature (TC)
Water inlet temperature (TWI)
Water outlet temperature (TWO)
Water heater outlet temperature (THO)
Floor inlet temperature (TFI)
Hot water cylinder temperature sensor (TTW)
Motorized mixing valve position
Heat exchanger temperature (TE)
Outside air temperature (TO)
Refrigerant discharge temperature (TD)
Refrigerant suction temperature (TS)
Heat sink temperature (THS)
Current value (in the inverter)
Heat exchanger coil temperature (TL)
Compressor operating frequency
Number of revolutions of outdoor fan (lower)
Number of revolutions of outdoor fan (upper)
Outdoor PMV position x1/10
Micro computer energized accumulation time
Hot water compressor ON accumulation time
Cooling compressor ON accumulation time
Heating compressor ON accumulation time
Hydro unit AC pump operation accumulation time
Hot water cylinder heater operation accumulation time
Hydro unit heater operation accumulation time
Booster heater operation accumulation time
3) Press button to exit the test mode.
