10-5. Diagnosis Procedure for Each Check Code
Check code
[E01] / [–]
(TCC-L / AI-NET)
Check code name
Communication error between
indoor and remote controller
(Detected at remote controller side)
Cause of operation
1. Remote controller interconnecting cable
error
2. Indoor power supply error
3. Indoor P.C. board error
4. Remote controller address setup error
5. Remote controller P.C. board error
Is a group control operation?
Is power of each indoor unit turned on?
YES
YES
YES
YES
YES
YES
NO
NO
NO
NO
NO
NO
Is there no disconnection or
connector contact error on harness out
of terminal block of indoor unit?
Is the interconnection cable of
remote controllers (A/B) normal?
Is power applied to remote controller?
AB terminals: Approx. DC18V
Are two remote controllers used
without the correct identification?
Correct interconnection cable of
remote controller.
Correct connection
and check circuit cabling.
Check power connection status of
indoor unit. (Turn on power again.)
Check indoor P.C. board.
Defect
®
Replace
Change one to main/other to sub.
(Remote controller address connector)
Check remote controller P.C. board.
Defect
®
Replace
Check code name
Remote controller sending error
Cause of operation
Signal could not be sent to indoor unit.
Check the communication wire of the remote
controller.
* It is not displayed on 7-segment display of the central control controller.
Check code
[E02] / [–]
(TCC-L / AI-NET)
YES
NO
Is communication wiring between
remote controller and indoor unit correct?
Sending circuit error of the remote controller
®
Replace remote controller.
Correct the communication wiring.
Check code
[E03] / [97]
(TCC-L / AI-NET)
Check code name
Communication error between
indoor and remote controller
(Detected at indoor side)
Cause of operation
No communication from remote controller and
communication adaptor
This error is detected when the indoor unit cannot receive a signal from the remote controller.
Check communication wiring of the remote controllers A and B.
As communication is impossible, this fault code [E03] is not displayed on the main remote controller.
It is displayed on TCC-LINK central controller.
Check code
[E04] / [04]
(TCC-L / AI-NET)
Check code name
Indoor/Outdoor
communication circuit error
(Detected at indoor side)
Cause of operation
1. Power of outdoor unit was firstly turned on.
2. Connection error of communication line
between indoor and outdoor
3. Terminal resistance setup error on outdoor
header unit.
4. Address setup error
For details, refer to “Troubleshooting in test operation”.
Is address setup correct?
Is there no noise, etc?
YES
YES
YES
YES
YES
YES
NO
NO
NO
NO
NO
NO
Was power turned on in order
of indoor unit
®
outdoor unit?
Is the terminator resistor
setup of outdoor unit normal?
Is power applied to fuse (F03)
on indoor P.C. board?
Is connection (U1/U2 terminals) of
indoor/outdoor interconnection cable normal?
Check indoor P.C. board.
Defect
®
Replace
Check connection of interconnection cable
between indoor and outdoor is correct, and
then connect communication line connector
on indoor P.C. board (CN40) to CN44 (EMG).
Correct interconnection cable.
Turn on power again in order of
indoor unit
®
outdoor unit.
Correct the terminator resistor setup.
(SW30-2)
Set up address again.
Check noise etc. and eliminate it if any.
To Next Page
