2. Grasp the disc tray gently and pull until it is fully opened.
Figure 4-9 Pressing the eject button and pulling the disc tray open
1. Eject button 2. Disc tray
3. Lay the disc in the disc tray with its label facing to the front of the
computer.
Figure 4-10 Inserting a disc
1. Laser lens
When the disc tray is fully opened, the edge of the computer will cover the
disc tray slightly. Therefore, you will need to turn the disc at an angle when
you place it in the disc tray. After seating the disc, however, make sure it
lies flat.
Do not touch the laser lens or any portion of its surrounding casing as
this could cause misalignment.
Prevent foreign objects from entering the drive. Check the surface of
the disc tray, especially the area behind the front edge of the disc tray,
to make sure there are no such objects before closing the drive.
4. Press gently at the center of the disc until you feel it click into place.
The disc should lie below the top of the spindle, flush with the spindle
base.
5. Push the center of the disc tray to close it. Press gently until it locks
into place.
User's Manual 4-14
