DC IN 19V jack The AC adaptor connects to this socket to power
the computer. Please note that you should only
use the model of AC adaptor supplied with the
computer at the time of purchase (depends on
the model you purchased) - using the wrong AC
adaptor can cause damage to the computer.
Underside
The following figure shows the underside of the computer.
Figure 3-5 The underside of the computer
1. Stereo speakers 2. Security lock slot
Stereo speakers The speakers emit sound generated by your
software as well as audio alarms generated by
the system.
Security lock slot A security cable can be attached to this slot and
then connected to a desk or other large object in
order to deter theft of the computer.
Wireless Keyboard
Front
The following figure shows the front of the wireless keyboard.
Figure 3-6 Front of the wireless keyboard
