4-3. Outdoor Unit (RAS-09SASX)
FILE NO. SVM-07021
No. Parts name Type Specifications
Output (Rated) 780W, 2 poles, 1 phase, 220-240V~, 50Hz
1 Compressor QK164PBA Winding resistance (Ω) C-R C-S
(at 20°C) 3.51 3.67
Output (Rated) 20W, 6 poles, 1 phase, 220-240V~, 50Hz
2 SKF-240-20B Winding resistance (Ω) Red-Black White-Black
(at 20°C) 235.2 260.1
3
Running capacitor
DS451155NPQB AC 450V~, 1.5µF
(for fan motor)
4
Running capacitor
RS44B356U0215S AC 440V~, 35µF
(for compressor)
(for outdoor)
Fan motor
Overload relay5
LPAP960B
U/T: 6.1A(80°C), Open: 135±5°C, Close: 75±11°C
