4. SPECIFICATION OF ELECTRICAL PARTS
4-1. Indoor Unit (RAS-07SKSX, RAS-09SKSX)
4-2. Outdoor Unit (RAS-07S2AX)
No. Parts name Type Specifications
Output (Rated) 605W, 2 poles, 1 phase, 220 – 240V~, 50Hz
1 Compressor PH108X1C-4DZDN2 Winding resistance (Ω) C-R C-S
(at 20°C) 4.84 4.40
Output (Rated) 20W, 6 poles, 1 phase, 220 – 240V, 50Hz
2 SKF-240-20B Winding resistance (Ω) Red-Black White-Black
(at 20°C) 235.2 260.1
3
Running capacitor
DS451155NPQB AC 450V~, 1.5µF
(for fan motor)
4
Running capacitor
RS44B256U0213S AC 440V~, 25µF
(for compressor)
(for outdoor)
Fan motor
Overload relay
5
JMRA99208-9102
U/T: 4.2A (80°C), Open: 135±5°C, Close: 69±11°C
No. Parts name Type Specifications
1 Fan motor (for indoor) AFS-220-20-4AR AC Motor with 145°C thermo fuse
2 Thermo sensor (TA-sensor) 10kΩ at 25°C
3 Micro power module (M01) RM1260V AC220- 240V~, 50/60Hz
4 Microcontroller unit (IC30) TMP87CM40AFG-6P69
5 Heat exchanger sensor
10kΩ at 25°C
(TC-sensor)
6 Bridge rectifier (DB01) DB105G 1A, 600V
7 Capacitor (C63) EKMH401VSN470MP20S 47µF, 400V
8 Fuse (F01) BET6.3A 6.3A, 250VAC
9 Varistor (R21, R22) TND15G-561KB0SLAA0 560V
10 Louver motor 24BYJ48 12VDC
11 Relay (Comp., RY01) G4A-1A-E-CA 20A/250V, 12VDC
12 Line filter (L01) LC*SS11V-06270 27mH, 600mA
µ
13 Resistor (R319) RF-2TK5R6 5.6Ω, 2W
