1. SPECIFICATIONS
MO DE L
RAS-07SKSX / RAS-07S2AX
RAS-09SKSX / RAS-09SASX
ITE M Cooling
Capacity
220V 240V 220V 240V
kW 2.00 2.00 2.50 2.50
Phase 1
Power source V 220 - 240
Hz 50
Power consumption kW 0.62 0.66 0.84 0.88
Power factor % 98 96 98 98
Running Indoor A 0.15
current Outdoor A 2.72 2.72 3.75 3.60
Starting current A 13 15
Moisture removal lit/h 0.5 1.2
Noise
Indoor (H/M/L) dB 40/35/30 43/38/33
Outdoor dB 46 47 46 47
Refrigerant
Name of refrigerant R22
Rated amount kg 0.58 0.58
Refrigerant control Capillary tube
Gas side size mm
9.52
Connection type Flare connection
Liquid side size mm 6.35
Interconnection
Connection type Flare connection
pipe
Maximum length
m 10.0
10.0
(One way)
Maximum height
m5 5
difference
INDOOR UNIT RAS-07SKSX RAS-09SKSX
Height mm 250
Dimensions Width mm 740
Depth mm 185
Net weight kg
Evaporator type Finned tube
Indoor fan type Cross flow fan
Air volume
High fan m
3
/h
430
470
Fan motor output W 20
Air filter Honeycomb woven filter with PP frame
OUTDOOR UNIT RAS-07S2AX RAS-09SASX
Height mm 530
Dimensions Width mm 660
Depth mm 240
Net weight kg 25
Condenser type Finned tube
Outdoor fan type Propeller fan
Airflow volume m
3
/h
1580
1640
Fan motor output W 20 20
Compressor
Model PH108X1C-4DZDN2
Output W 605 780
Safety device
Fuse, Overload relay
Louver type Automatic louver
Usable outdoor temperature range
°C
21 ~ 43
1660 1720
8
QK164PBA
30
390
350
510
Low fan
Medium fan
m
3
/h
m
3
/h
