Item Operation flow and applicable data, etc. Description
2. Indoor fan
motor
control
3) In heating operation, the mode changes to [LL] if thermostat is
turned off.
4) If Ta ≥ 25°C when heating operation has started and when defrost
operation has been cleared, the air conditioner operates with (H)
mode or higher mode for 1 minute after Tc entered in E zone of cool
air discharge preventive control.
Tcj:
Indoor heat exchanger
sensor temperature
tap COOL HEAT
External static pressure selection
10Pa 20Pa 35Pa 45Pa
F1 HH 1020 1120 1200 1260
F2 HH 1020 1120 1200 1260
F3 H+ 960 1020 1120 1160
F4 H+ 960 1020 1120 1160
F5 H 880 940 1020 1040
F6 H 880 940 1020 1040
F7 L+ 820 870 940 980
F8 L+ 820 870 940 980
F9 L 740 780 850 890
FA L 740 780 850 890
FB 730 730 770 820
FC 730 730 770 820
FD LL LL 610 610 610 610
Revolution speed of indoor fan (rpm)

M07G3DV, M10G3DV
tap COOL HEAT
External static pressure selection
10Pa 20Pa 35Pa 45Pa
F1 HH 1120 1160 1240 1300
F2 HH 1120 1160 1240 1300
F3 H+ 1000 1040 1140 1200
F4 H+ 1000 1040 1140 1200
F5 H 920 970 1040 1120
F6 H 920 970 1040 1120
F7 L+ 830 870 930 980
F8 L+ 830 870 930 980
F9 L 740 780 840 870
FA L 740 780 840 870
FB 730 730 770 820
FC 730 730 770 820
FD LL LL 610 610 610 610

M13G3DV
tap COOL HEAT
External static pressure selection
10Pa 20Pa 35Pa 45Pa
F1 HH 1020 1120 1220 1260
F2 HH 1020 1120 1220 1260
F3 H+ 960 970 1100 1140
F4 H+ 960 970 1100 1140
F5 H 810 810 960 1020
F6 H 810 810 960 1020
F7 L+ 730 750 810 960
F8 L+ 720 750 810 960
F9 L 660 700 760 800
FA L 630 670 720 760
FB 630 630 660 680
FC 630 630 640 660
FD LL LL 550 550 550 550

M16G3DV
