Toshiba ras-m16g3dv-e - Indoor Unit Parts List

– 86 –
Location
No.
Part No. Description
Q’ty/Set
RAS-M**G3DV-E RAS-M**G3DV-ND RAS-M**G3DV-TR
07 10 13 16 07 10 13 16 07 10 13 16
201 43H22003 CASE, FAN, UPPER 2 2 2 2 2 2 2 2 2
202 43H22004 CASE, FAN, UPPER 2 2 2
203 43H22006 CASE, FAN, LOWER 2 2 2 2 2 2 2 2 2
204 43H22007 CASE, FAN, LOWER 2 2 2
205 43H21004 MOTOR, FAN 1 1 1 1 1 1 1 1
206 43H21007 MOTOR, FAN 1 1 1 1
207 43H00021 PLATE, INLET 1 1 1 1 1 1 1 1 1
208 43H00022 PLATE, INLET 1 1 1
209 43H70001HOSE, DRAIN 111111111111
210 43H44009 REFRIGERATION CYCLE ASSY 1 1 1 1 1 1 1 1 1
211 43H44010 REFRIGERATION CYCLE ASSY 1 1 1
212 43H49003 SOCKET 1 1 1 1 1 1 1 1 1
213 43H49004 SOCKET 1 1 1
214 43H49006SOCKET 111111111111
215 43H49007 NUT, FLARE 1 1 1 1 1 1 1 1 1
216 43H49008 NUT, FLARE 1 1 1
217 43H49010NUT, FLARE 111111111111
218 43H72001 PAN ASSY, DRAIN 1 1 1 1 1 1 1 1 1
219 43H72002 PAN ASSY, DRAIN 1 1 1
220 43H79001CAP, DRAIN 222222222222
221 43H77001PUMP, DRAIN 111111111111
222 43H19006 COVER ASSY, SIDE 1 1 1 1 1 1111111
223 43H19007COVER, PIPE 111111111111
224 43H00024 FLANGE, OUTLET 1 1 1 1 1 1 1 1 1
225 43H00025 FLANGE, OUTLET 1 1 1
226 43H70002HOSE, DRAIN 111111111111
227 43H79002BAND, HOSE 111111111111
228 43H20006 FAN, MULTI BLADE 2 2 2 2 2 2 2 2 2
229 43H20007 FAN, MULTI BLADE 2 2 2
230 43H51002SWITCH, FLOAT 111111111111
231 43H47008HOLDER, SENSOR(TC) 222222222222
232 43H60006FILTER, NOISE 111111111111
233 43H58011UNIT, SIGNAL RECEIVING 111111111111
234 43H66001 REMOTE CONTROLLER,
WIRELESS
111111111111
235 43H66002HOLDER, REMOTE CONTROL 111111111111
