1-11-19 E3NG1TR
FLOW CHART NO.15
Audio can not be playbacked normally in the linear audio mode. (E-E mode is normal.)
Is there no dirt on the surface of ACE head assembly?
Is the audio signal supplied to Pin(5) of IC301?
Replace P1(AV
ASSEMBLY).
Is the audio signal outputted to Pin(11) of IC301?
Check the line between Pin(11)
of IC301 and Pin(80) of IC451,
and replace P1(AV ASSEMBLY).
Readjust the height of the ACE head assembly.
Clean the surface of ACE head assembly.
Ye s
Is the height of ACE head assembly appropriate?
Ye s
Replace DECK ASSEMBLY (1B1).
Ye s
NoYe s
No
No
No
To Next Page
