Satellite A210/ A215, Satellite Pro A210, EQUIUM A210, SATEGO A210 Series Maintenance Manual
C-10
C.10 PJP1
Table C-10 AC Adaptor Connector pin assignments (4-pin)
Pin No. Signal name I/O Pin No. Signal Name I/O
1 DC_IN_S1 I 2 DC_IN_S2 -
3 GND - 4 GND -
C.11 JP39
Table C-11 Microphone I/F pin assignments (6-pin)
Pin No. Signal name I/O Pin No. Signal Name I/O
1 GND - 2 MIC1_L I
3 MIC1_R I 4 MIC_SENSE I
5 GND - 6 NC -
C.12 JP38
Table C-12 Head phone Connector pin assignments (6-pin)
Pin No. Signal name I/O Pin No. Signal Name I/O
1 GND - 2 HP_L O
3 HP_R O 4 HP_SENSE I
5 GND - 6 NC -
