4 Replacement Procedures
Satellite A210/ A215, Satellite Pro A210, EQUIUM A210, SATEGO A210 Series Maintenance Manual
4-23
4.9 Keyboard
Removing the Keyboard
Before removing the keyboard, remove the battery and any optional devices. Follow the steps
below to remove the keyboard:
1. Open the display panel.
2. Insert a thin tool such as a flat screwdriver into the gap between the strip cover and
keyboard to lever the strip cover up.
Figure 4-20 Removing the strip cover
NOTE: The display panel must be fully open in order to remove the strip cover.
3. Remove the strip cover.
Figure 4-21 Removing the strip cover
To Next Page
