Capacities
CTX100 Maximum Capacity Configuration Examples
16 Strata CTX General Description 11/02
Table 11 CTX100 Base and Expansion Digital Telephones and with T1 and/or PRI lines
Table 12 CTX100 Base Cabinet Only with Analog Tie, DID and /or Ground Start Lines
Table 13 CTX100 Base and Expansion Cabinet with Analog Tie, DID and/or Ground Start Lines
8 Universal Slots
72 Stations (Max.)
64 lines (Max.)
112 Stations + T1 and/or PRI lines combined
(Max.)
Stations
T1 and/or PRI lines
1
1. PRI lines are limited to 48B channels.
72 40/40
64 48/48
56 56/48
48 64/48
4 Universal Slots
40 Stations (Max.)
16 CO lines (Max.)
40 Stations + Analog Tie, DID, Ground Start Lines
combined (Max.)
Stations Analog Tie, DID, and/or Ground Start Lines
40 4 line (Ground Start only)
32 8 lines (4 Tie/DID max.).
24 8 line any type
16 12 line any type
0 16 line any type
8 Universal Slots
72 Stations (Max.)
32 CO lines (Max.)
80 Stations + Analog Tie, DID and/or ground start Lines
combined (Max.)
Stations Analog Tie, DID, and/or Ground Start Lines
72 12 lines (4 Tie/DID max.)
64 16 lines (8 Tie/DID max.)
56 16 lines (12 Tie/DID max.)
48 16 lines any type
48 20 lines (16 Tie/DID max.)
32 24 lines any type
16 28 lines any type
