Category 5 Twisted-Pair Cross Cable (UTP Cable) ZCA**********
This cable is used for wiring in a room (operator room, for example) or in a cabinet. In
particular, it is used for connecting one hub to another.
• Connector used: RJ-45 connector
• Cable shape
Figure E-3 10BASE-T Twisted-Pair Cable
• Specifying cable length
Specify a cable as follows: The maximum cable length is 30 m.
Cable length
10BASE-T twisted-pair cable
ZCA101A
501 1
Cable length → 50 㩷䍃䍃㩷 1 → 5m 㩷
cm 䍃 × 䍃 10
n
