Toshiba TLP-T50M - Page 39

2-5
PJ402 (MAIN) CN202 (POWER UNIT (APS-M423))
1 +3.3V
2 +3.3V
3 +3.3V
4 AGND
5 AGND
6 AGND
7 +6.5V
8 AGND
9NC
10 -10.5V
11 AGND
12 NC
13 +15.5V
14 +15.5V
15 AGND
16 AGND
17 NC
18 +15.5V
19 AGND
20 NC
21 S+5V
22 AGND
23 MCU-POW-PWRON
24 AGND
CN105 (MAIN POWER UNIT)
CN1 (LAMP DRIVER)
1 +370V LIVE
2NC
3 GND LIVE
