Toshiba TOSDIC-CIE DS Hardware Operation Manual

2. System component
12
Table 2.5 SLP06 module specification
Item Specification
Name Loop module
Model name SLP06 (pulse output type)
Name Loop module (pulse output type)
Analog input (AI)
Number of points: 6 Signal: 1 to 5VDC Input precision:
±
0.2%
Operation output (MV) Number of points: 4 Signal: pulse signal (no voltage)
Valve angle input (VP)
Number of points: 4 Signal: 1 to 5VDC Input precision:
±
0.2%
Analog output (AO)
Number of points: 2 Signal: 1 to 5VDC Output precision:
±
0.2%
Digital input (DI) Number of points: 4 Signal: No voltage
Input-output
Digital output (DO) Number of points: 4 Signal: No voltage (FET open drain)
Applicable communication module SBIF3
Applicable unit ULCU12
Online insertion/removal Available
Redundancy Redundancy available
Failure diagnosis
Analog input reference voltage, analog input deviation*, I/O bus
transmission, CPU (WDT), memory
* Redundant configuration only. Comparative diagnosis of the input
counts of redundant 2 units of SLP05 is performed with SBIF3.
Power supply voltage
24VDC
±
10%
System
power
supply
Current consumption 250mA (@24VDC)
Insulation resistance
100M
Ω
or more
Withstand voltage 500VAC 1 minute between FG and power supply (module single unit)
Outside dimension
40W
×
90H
×
95D
㎜
(excluding protrusions)
Weight 170g
