Toshiba TOSVERT VF-AS3 Manual

E6582051
- 23 -
4.2.3. Relation common parameters for VF-S15/AS3
Title
Communi
cation No.
Function Description
c152
C152
PROFIdrive Profile monitor
0：Telegram 1 (PROFIdrive)
1：Telegram 100 (Vender Spec. 1)
2：Telegram 101 (Vender Spec. 2)
3
：
Telegram 102 (Vender Spec. 3)
c517-
c522
C517-
C522
MAC address monitor (*1)
The MAC address of the option module.
[
c517
-
c518
-
c519
-
c520
-
c521
-
c522
]
c524-
c527
C524-
C527
IP address monitor
The current IP address of the option module.
c528-
c531
C528-
C531
Subnet mask monitor
The subnet mask actual of the option module.
Refer to "4.3.2 Assigning IP addresses" for the
details.
c532-
c535
C532-
C535
Default gateway monitor
The gateway IP address actual of the option
module.
Refer to "4.3.2 Assigning IP addresses
" for the
details.
c536
C536 Ethernet Error monitor
Monitor of the Ethernet error.
0: No error
1: PROFINET I/O timeout
2: Network overload
3: Loss of Ethernet carrier
9: duplicated IP address.
10: No valid IP.
17: Application I/O configuration error
(*1): These values are displayed by decimal number format on panel of VFS15/AS3.
