8.7. "43 (0x2B) Read Device identification" function
The Modbus request is used to read the device identification.
Example in VFS15-2004PM with device name “PROFINET” is shown below.
Inverter supports Basic Device ID and Regular Device ID.
Request format:
Byte
Meaning
0
Function Code = 2Bh
0x2B
1
Type of MEI
0x0E
2
Read Device ID code
0x01: Basic
0x02: Regular
3
Object ID
0x00
Response format: Unit ID = 0 – 248 (Inverter)
Byte
Meaning
Example value
0
Function Code = 2Bh
0x2B
1
Type of MEI
0x0E
2
Read Device ID code
01: Basic
02: Regular
3
Conformity Level
0x02*
4
More Follows
0: No more Object
5
Next Object Id
0
6
Number Of Objects
3 for Basic.
6 for Regular or Extended
7
Obj 0 Id  Vendor Name
0
8
Obj 0 length
7
9-15
Obj 0 value
“TOSHIBA”
16
Obj 1 Id  ProductCode
1
17
Obj 1 length
13
18-30
Obj 1 value
“VFS15-2004PM”
31
Obj 2 Id  Version
2
32
Obj 2 length
5
33-37
Obj 2 value
“11200”
38
Obj 4 Id  Product Name
4
Only for
Regular
39
Obj 4 length
6
40-45
Obj 4 value
“VF-S15”
46
Obj 5 Id  Model Name
5
47
Obj 5 length
3
44-58
Obj 5 value
“TSB”
59
Obj 6 Id  UserApplicationName
6
60
Obj 6 length
16
61-80
Obj 6 value
“PROFINET”
*When PNE001Z (no suffux) is used, Conformity Level is 0x81 (basic identification stream access and
individual access), but please use it as 0x02 (regular identification stream access only).
